GPI 15 GPM 12V Fuel Transfer Pump
GPI® M-150 Series
SKU 110000-100
| MODEL M-150S-AU
| MODEL M-150S-MU
| MODEL M-150S-EM
| MODEL M-150S-PO
| MODEL M-150S-E-PO
| MODEL M-150-AU with Filter
Original price
$319.99
-
Original price
$549.99
Original price
$489.99
$319.99
-
$549.99
Current price
$489.99
Fluid Statement
Gasoline up to E15 | Diesel up to B20 | Kerosene Gasoline up to E15 | Diesel up to B20 | Kerosene Gasoline up to E15 | Diesel up to B20 | Kerosene Gasoline up to E15 | Diesel up to B20 | Kerosene | AVGAS | Jet A Gasoline up to E15 | Diesel up to B20 | Kerosene | AVGAS | Jet A Gasoline up to E15 | Diesel up to B20 | Kerosene
The GPI M-150S Fuel Transfer Pump is the best-selling retail fuel transfer pump, providing longer run times and award-winning performance year-over-year. Delivering flow rates up to 15 GPM (57 L/min), available in five pump models, the M-150 Series is the pump of choice for agricultural, automotive, and construction applications dispensing gasoline, diesel fuel, and kerosene. Available in a wide selection of configurations with an automatic or manual nozzle, mechanical meter combination, lockable or standard nozzle holders, and a variety of fuel hose lengths. Whether you are harvesting crops, gearing up for your next race, or refueling your fleet of mowers, our M-150 provides reliable flow rates with minimal downtime.
Features & Benefits
- DURABLE ALUMINUM HOUSING: Manufactured from high-quality diecast aluminum, our fuel transfer pump with automatic shut-off nozzle is extremely dependable and lightweight and will put minimal stress on your tank bung. The powder-coated aluminum housing is rugged and corrosion-resistant to withstand years of work in any application.
- ROTARY GEAR DESIGN: The rotary gear pump is engineered with fewer moving parts, which means less friction and wear on its components. Thus this rotary gear pump will have fewer needed repairs and longer life than a rotary vane pump. When you need reliable performance GPI’s gear pumps are over engineered to deliver.
- 2-YEAR WARRANTY: Our M-150S GPI fuel transfer pumps come with a 2-year warranty and are UL Listed Motor and CSA Certified. Feel confident in knowing that your fuel pump has been providing longer run times and award-winning performance.
- EASY-TO-USE: The 12-VDC motor of our fuel transfer pumps is highly efficient as it delivers gasoline, diesel fuel, ethanol blends, and kerosene at flow rates up to 15GPM. Additionally, the innovative spin collar design of our fuel transfer pump makes installation fast and easy!
- Lockable nozzle holder protects your investment and deters theft.
- strainer and poppet access makes maintenance quick and easy.
- Designed for permanent mounting on vented storage tanks
- A convenient spin collar and factory-installed power cord make installation safe and easy.
- DURABLE ALUMINUM HOUSING: Manufactured from high-quality diecast aluminum, our fuel transfer pump with manual unleaded nozzle is extremely dependable and lightweight and will put minimal stress on your tank bung. The powder-coated aluminum housing is rugged and corrosion-resistant to withstand years of work in any application.
- ROTARY GEAR DESIGN: The rotary gear pump is engineered with fewer moving parts, which means less friction and wear on its components. Thus this rotary gear pump will have fewer needed repairs and longer life than a rotary vane pump. When you need reliable performance GPI’s gear pumps are over engineered to deliver.
- EASY-TO-USE: The 12-VDC motor of our fuel transfer pumps is highly efficient as it delivers gasoline, diesel fuel, ethanol blends, and kerosene at flow rates up to 15GPM. Additionally, the innovative spin collar design of our fuel transfer pump makes installation fast and easy!
- 2-YEAR WARRANTY: Our M-150S GPI fuel transfer pumps come with a 2-year warranty and are UL Listed Motor and CSA Certified. Feel confident in knowing that your fuel pump has been providing longer run times and award-winning performance.
- Lockable nozzle holder protects your investment and deters theft
- Strainer access for easy maintenance
- Longer pump life means more operating hours which equals greater value.
- Designed for permanent mounting on vented storage tanks.
- DURABLE ALUMINUM HOUSING: Manufactured from high-quality diecast aluminum, our fuel transfer pump with manual shut-off nozzle is extremely dependable and lightweight and will put minimal stress on your tank bung. The aluminum housing is rugged and corrosion-resistant to withstand years of work in any application.
- ROTARY GEAR DESIGN: The rotary gear pump is engineered with fewer moving parts, which means less friction and wear on its components. Thus this rotary gear pump will have fewer needed repairs and longer life than a rotary vane pump. When you need reliable performance GPI’s gear pumps are over engineered to deliver.
- EASY-TO-USE: The 12-VDC motor of our fuel transfer pumps is highly efficient as it delivers gasoline, diesel fuel, ethanol blends, and kerosene at flow rates up to 15GPM.
- 2-YEAR WARRANTY: Our M-150S GPI fuel transfer pumps come with a 2-year warranty and are UL Listed Motor and CSA Certified. Feel confident in knowing that your fuel pump has been providing longer run times and award-winning performance.
- Circuit breaker motor protection extends motor life.
- Designed for permanent mounting on vented storage tanks.
- DURABLE ALUMINUM HOUSING: Manufactured from high-quality diecast aluminum, our fuel transfer pump (pump only) is extremely dependable and lightweight and will put minimal stress on your tank bung. The aluminum housing is rugged and corrosion-resistant to withstand years of work in any application.
- ROTARY GEAR DESIGN: The rotary gear pump is engineered with fewer moving parts, which means less friction and wear on its components. Thus this rotary gear pump will have fewer needed repairs and longer life than a rotary vane pump. When you need reliable performance GPI’s gear pumps are over engineered to deliver.
- EASY-TO-USE: The 12-VDC motor of our fuel transfer pumps is highly efficient as it delivers gasoline, diesel fuel, and kerosene at flow rates up to 15GPM. Additionally, the innovative spin collar design of our fuel transfer pump makes installation fast and easy!
- 2-YEAR WARRANTY: Our M-150S GPI fuel transfer pumps come with a 2-year warranty and are UL Listed Motor and CSA Certified. Feel confident in knowing that your fuel pump has been providing longer run times and award-winning performance.
- Lockable nozzle cover protects your investment and deters theft
- Unique strainer and poppet design allows for easy access and maintenance
- Designed for stationary locations in fleet, agriculture or Industrial applications
- Designed for stationary locations in fleet, agriculture or Industrial applications
- Light-weight aluminum body is easy to handle and reduces tank stress
- UL Listed Motor and CSA Certified
- Includes a 10 micron, 1-12 UNF particulate filter that removes debris from fuel that may damage your equipment.
- Higher flow rate reduces time spent refueling.
- Convenient spin collar for easy installation; Overload protected motor extends motor life.
- Powder-coated, light-weight aluminum body provides corrosion resistance and reduces tank stress.
- Lockable nozzle holder protects your investment and deters theft.
- Designed for permanent mounting on vented storage tanks.
- Low provide design does not block line of vision.
- UL Listed Motor and CSA Certified
Specifications
- Input:
- 12V (DC)
- Fuse:
- 25 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Dispensing Hose:
- 12 ft.(3.7m) x 3/4 in.
- Nozzle:
- 3/4 in. FNPT Inlet, Automatic Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401150612
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
- Input:
- 12V (DC)
- Fuse:
- 25 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Dispensing Hose:
- 12 ft.(3.7m) x 3/4 in.
- Nozzle:
- 3/4 in. FNPT Inlet, Manual Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401150605
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
- Input:
- 12V (DC)
- Fuse:
- 25 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Direct Mount, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Dispensing Hose:
- 10 ft. (3.05m) x 3/4 in.
- Nozzle:
- 3/4 in. FNPT Inlet, Manual Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401100945
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
- Input:
- 12V (DC)
- Fuse:
- 25 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Not included
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG Power cord
- Dispensing Hose:
- Not included
- Nozzle:
- Not included
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr
- UPC:
- 031401000481
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 1, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
- Input:
- 12V (DC)
- Fuse:
- 25 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Direct Mount, 2in. MNPT
- Suction Pipe:
- Not included
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG Power cord
- Dispensing Hose:
- Not included
- Nozzle:
- Not included
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401112405
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 1, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
- Input:
- 12V (DC)
- Fuse:
- 25 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Dispensing Hose:
- 12 ft.(3.7m) x 3/4 in.
- Nozzle:
- 3/4 in. FNPT Inlet, Automatic Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401009040
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
Also Available At
Manuals / Documents
Applications
What's in the Box
Includes the M-150S 15 GPM pump with spin collar, automatic unleaded nozzle, lockable nozzle holder, dispensing hose, factory-installed power cord, telescoping suction pipe, tank adapter, fuse assembly, owners manual.
Includes the M-150S 15 GPM pump with spin collar, manual unleaded nozzle, lockable nozzle holder, dispensing hose, factory-installed power cord, telescoping suction pipe, tank adapter, fuse assembly, owners manual.
Includes the M-150S 15 GPM pump, manual unleaded nozzle, nozzle holder, dispensing hose w/static wire, factory-installed power cord, telescoping suction pipe, tank adapter, fuse assembly, owners manual.
Includes the M-150S 15 GPM pump with spin collar, power cord, lockable nozzle holder, tank adapter, fuse assembly, owners manual.
Includes the M-150S 15 GPM pump with direct mount, nozzle holder, fuse assembly owners manual.
Includes the M-150S 15 GPM pump, automatic unleaded nozzle, dispensing hose, factory-installed power cord, filter with adapter and installation kit, telescoping suction pipe, tank adapter, fuse assembly, owners manual.
