Turbine Flow Meter, Battery Powered Display, Nylon Body for DEF
GPI® 01N DEF Series
SKU 113255-24
| MODEL 01N31GM-U
| MODEL 01N31LM-U
Original price
$242.00
-
Original price
$242.00
Original price
$242.00
$242.00
-
$242.00
Current price
$242.00
Recommended for use with these fuels:
DEF (Diesel Exhaust Fluid) DEF (Diesel Exhaust Fluid)The GPI Digital diesel exhaust fluid meters are suitable for inline or end-of-hose installation for use with DEF, water, or similar fluids. These electronic flowmeters are virtually maintenance-free and provide continuous measurement, flow range of 3 to 30 GPM (10-100 L/min). This meter meets ISO 22241-2 Annex C, D, E, F, G, H, I, Diesel Exhaust Fluid (DEF)/Adblue standards.
Features & Benefits
- Auto-off display turns off after 1 minute of inactivity to extend battery life.
- 4-digit electronic display reads batch and cumulative totals
- Auto-off display turns off after 1 minute of inactivity to extend battery life.
- one cumulative and one resettable batch total.
Specifications
- Flow Range:
- 3 - 30 GPM (10-100 L/min)
- Accuracy (% of Reading):
- +/- 5%
- Technology:
- Turbine
- Pressure Rating:
- 150 PSI (10.34 bar)
- Operating Temperature:
- 14° to 130° F (-10° to 55° C)
- Housing Material:
- Nylon
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401001235
- Approvals:
- CE. Complies with the requirements of the EMC Directive 89/336/EEC.
- Flow Range:
- 3 - 30 GPM (10-100 L/min)
- Accuracy (% of Reading):
- +/- 5%
- Technology:
- Turbine
- Pressure Rating:
- 150 PSI (10.34 bar)
- Operating Temperature:
- 14° to 130° F (-10° to 55° C)
- Housing Material:
- Nylon
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401007824
- Approvals:
- CE. Complies with the requirements of the EMC Directive 89/336/EEC.
Manuals / Documents
Applications
What's in the Box
Digital DEF meter, (2) alkaline AAA batteries, Owners manual
Digital DEF meter, (2) alkaline AAA batteries, Owners manual
