GPI 18 GPM 12V Fuel Transfer Pump
GPI® M-180 Series
SKU 110612-02
| MODEL M-180S-AU W/FILTER
| MODEL M-180S-ML W/FILTER
| MODEL M-180S-AU
| MODEL M-180S-ML
| MODEL M-180S-PO
Original price
$449.99
-
Original price
$629.99
Original price
$629.99
$449.99
-
$629.99
Current price
$629.99
Recommended for use with these fuels:
Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Avgas (100LL) | Jet A | Jet A-1The GPI M-180 Series Fuel Transfer Pump provides longer run times and reliable performance year after year. Delivering flow rates up to 18 GPM (69 L/min), the M-180S is the pump of choice for agricultural, automotive, and construction applications dispensing gasoline, diesel fuel, and kerosene. Available in a wide selection of configurations with an automatic or manual nozzle, and filter kit combinations. The M-180 Series is durable, manufactured from high-quality die-cast aluminum, easy to use, and engineered to last featuring a self-priming rotary gear design.
Features & Benefits
- Includes an 18 GPM 10 micron, 1-12 UNF particulate filter that removes debris from fuel that may damage your equipment.
- Higher flow rate reduces time spent refueling.
- Convenient spin collar for easy installation; Overload protected motor extends motor life.
- Powder-coated motor can and light-weight aluminum body provides corrosion resistance and reduces tank stress.
- Lockable nozzle holder protects your investment and deters theft.
- Designed for permanent mounting on vented storage tanks.
- Low profile design does not block line of vision.
- UL Listed Motor, 2-year warranty
- Includes an 18 GPM 10 micron, 1-12 UNF particulate filter that removes debris from fuel that may damage your equipment
- Higher flow rate reduces time spent refueling.
- Convenient spin collar for easy installation; Overload protected motor extends motor life
- Powder-coated motor can and light-weight aluminum body provides corrosion resistance and reduces tank stress
- Lockable nozzle holder protects your investment and deters theft
- Designed for permanent mounting on vented storage tanks
- Low profile design
- UL Listed Motor
- More operating hours means longer pump life and greater value
- Convenient spin collar provides for easy installation and versatile pump mounting
- Powder-coated, lightweight aluminum body provides corrosion resistance and reduces tank stress
- Lockable nozzle holder protects your investment and deters theft
- Designed for permanent mounting on vented storage tanks
- Low profile design
- UL Listed Motor
- More operating hours means longer pump life and greater value
- Convenient spin collar provides for easy installation and versatile pump mounting
- Powder-coated, lightweight aluminum body provides corrosion resistance and reduces tank stress
- Lockable nozzle holder protects your investment and deters theft
- Designed for permanent mounting on vented storage tanks
- Low profile design
- UL Listed Motor
- More operating hours means longer pump life and greater value
- Convenient spin collar provides for easy installation and versatile pump mounting
- Powder-coated, lightweight aluminum body provides corrosion resistance and reduces tank stress
- Lockable nozzle holder protects your investment and deters theft
- Designed for permanent mounting on vented storage tanks
- Low profile design
- UL Listed Motor
- For ground-based refueling only. Do not use or mount in or on the aircraft. For use with aviation gasoline (AVGAS 100LL) and kerosene grade (JET A). User should consult NFPA 407 Standard for Aircraft Fuel Servicing for safety requirements during ground fuel servicing of aircraft using liquid petroleum fuels. This product has no actual or implied compliance with this standard.
Specifications
- Max. Flow Rate:
- 18 GPM (69 L/min)
- Voltage Input:
- 12V (DC)
- Technology:
- Rotary Gear
- Amps Rated:
- 20 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Max. Discharge Pressure:
- 15 PSI (1.03 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 5 ft. (1.5m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 15 ft. (4.5m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Corrosion-Resistant Diecast Aluminum
- Wetted Materials:
- Acetal | Aluminum | FKM | NBR | PPS | Stainless Steel
- Mounting Type/Thread:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Inlet:
- 1 in. FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- 12 ft. (3.7m) x 1 in. MNPT
- Nozzle:
- 3/4 in. FNPT Inlet, Automatic Shut-off, Unleaded
- Nozzle Holder Type:
- Lockable
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401000290
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Max. Flow Rate:
- 18 GPM (69 L/min)
- Voltage Input:
- 12V (DC)
- Technology:
- Rotary Gear
- Amps Rated:
- 20 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Max. Discharge Pressure:
- 15 PSI (1.03 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 5 ft. (1.5m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 15 ft. (4.5m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Wetted Materials:
- Acetal | Aluminum | FKM | NBR | PPS | Stainless Steel
- Mounting Type/Thread:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Inlet:
- 1 in. FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- 12 ft. (3.7m) x 1 in. MNPT
- Nozzle:
- 1 in. FNPT Inlet, Manual Shut-off, Diesel
- Nozzle Holder Type:
- Lockable
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401000245
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Max. Flow Rate:
- 18 GPM (69 L/min)
- Voltage Input:
- 12V (DC)
- Technology:
- Rotary Gear
- Amps Rated:
- 20 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Max. Discharge Pressure:
- 15 PSI (1.03 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 5 ft. (1.5m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 15 ft. (4.5m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Wetted Materials:
- Acetal | Aluminum | FKM | NBR | PPS | Stainless Steel
- Mounting Type/Thread:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Inlet:
- 1 in. FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- 12 ft. (3.7m) x 1 in. MNPT
- Nozzle:
- 3/4 in. FNPT Inlet, Automatic Shut-off, Unleaded
- Nozzle Holder Type:
- Lockable
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401103021
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Max. Flow Rate:
- 18 GPM (69 L/min)
- Voltage Input:
- 12V (DC)
- Technology:
- Rotary Gear
- Amps Rated:
- 20 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Max. Discharge Pressure:
- 15 PSI (1.03 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 5 ft. (1.5m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 15 ft. (4.5m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Wetted Materials:
- Acetal | Aluminum | FKM | NBR | PPS | Stainless Steel
- Mounting Type/Thread:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Inlet:
- 1 in. FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- 12 ft. (3.7m) x 1 in. MNPT
- Nozzle:
- 1 in. FNPT Inlet, Manual Shut-off, Diesel
- Nozzle Holder Type:
- Lockable
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401103014
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Max. Flow Rate:
- 18 GPM (69 L/min)
- Voltage Input:
- 12V (DC)
- Technology:
- Rotary Gear
- Amps Rated:
- 20 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG Power cord
- Max. Discharge Pressure:
- 15 PSI (1.03 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 5 ft. (1.5m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 15 ft. (4.5m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Wetted Materials:
- Acetal | Aluminum | FKM | NBR | PPS | Stainless Steel
- Mounting Type/Thread:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Not included
- Inlet:
- 1 in. FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- Not included
- Nozzle:
- Not included
- Nozzle Holder Type:
- Lockable
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401006285
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 1, Group D USA and Canada
Also Available At
Manuals / Documents
Applications
What's in the Box
M-180S-AU w/Filter Fuel transfer pump, Automatic shut-off, Unleaded nozzle, Dispensing hose, Factory-installed power cord, ,Telescoping suction pipe, Tank adapter, Fuse assembly, Particulate filter, Adapter and installation kit, Owners manual
M-180S-ML w/Filter Fuel transfer pump, Manual shut-off diesel nozzle, Dispensing hose, Factory-installed power cord, Telescoping suction pipe, Tank adapter, Fuse assembly, Particulate filter, Adapter and installation kit, Owners manual
M-180S-AU Fuel transfer pump, Automatic shut-off unleaded nozzle, Dispensing hose w/static wire, Factory-installed power cord, Telescoping suction pipe, Tank adapter, Fuse assembly, Owners manual
M-180S-ML Fuel transfer pump, Manual shut-off leaded nozzle, Dispensing hose w/static wire, Factory-installed power cord, Telescoping suction pipe, Tank adapter, Fuse assembly, Owners manual
M-180S-PO Fuel transfer pump, Power cord, Tank adapter, Fuse assembly, Owners manual
