50 Gallon per 100 Stroke Lever Action Fluid Transfer Hand Pump
GPI® HP-100-UL
SKU 114000-10
| MODEL HP-100-UL
Original price
$249.99
-
Original price
$249.99
Original price
$249.99
$249.99
-
$249.99
Current price
$249.99
Fluid Statement
Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Hydraulic Fluid | Transmission Fluid | 10W-30W OilThe GPI HP-100 Fluid Transfer pump is a premium fuel piston hand pump that is reliable and versatile, delivering the highest flow rate in the industry year after year. It is a single solution for multiple pumping applications, suitable for pumping fuels and motor oils. The HP-100 features a Dual-Flo® handle providing the user with the flexibility of operating the pump at two flow rates. A setting of 1/2-gallon per stroke cycle provides faster high-capacity flow for fuels. A 1/4-gallon setting allows for easier pumping of thicker fluids, such as motor oil, even in cold temperature conditions (-25°F / -32°C).
Features & Benefits
- Dual-Flo® piston design pumps fluid on both the push and pull stroke, Built -in anti siphon valve.
- Includes a low setting for low-volume, low-resistance pumping (1/4 gallon) and a high setting for high volume, high-resistance pumping (1/2 gallon).
- Light-weight aluminum body provides corrosion resistance and reduces tank stress.
- Lockable handle deters fluid theft. Fits a 2 in. NPT bung.
- Includes a 3/4 in. x 8 ft. (2.44 m) Nitrile fuel dispensing hose with static wire and metal nozzle.
- For use with diesel (diesel blends to B20), gasoline (alcohol blends up to E15), hydraulic fluid, kerosene and 30W oil.
- 2-yr Warranty
- U.L. listed to U.S. and Canadian standards.
Specifications
- Input:
- N/A
- Fuse:
- N/A
- Type:
- Piston
- Motor RPMs:
- N/A
- Motor HP:
- N/A
- Flow Rate:
- Up to 50 gallons per 100 stroke cycles
- Duty Cycle:
- N/A
- Working Pressure:
- N/A
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Wetted Materials:
- Aluminum
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Direct Mount, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- N/A
- Dispensing Hose:
- 8 ft. (2.44 m) x 3/4 in.
- Nozzle:
- Spout, Metal
- Housing:
- Corrosion-Resistant Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401114102
- Approvals:
- UL Listed Hand Operated Pump for Flammable and Combustible Liquids Per UL Subject 124
Also Available At
Manuals / Documents
Applications
What's in the Box
HP-100-UL Up to 50 Gal per 100 strokes hand pump, telescoping suction pipe, dispensing hose, lockable lever, owner's manual.
