GPI 15 GPM 24V Fuel Transfer Pump
GPI® M-240 Series
SKU 110000-70
| MODEL M-240S-MU
| MODEL M-240S-PO
Original price
$399.99
-
Original price
$479.99
Original price
$479.99
$399.99
-
$479.99
Current price
$479.99
Fluid Statement
Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Avgas (100LL) | Jet A | Jet A-1
The GPI M-240S Fuel Transfer Pump is the 24V DC pump of choice for agricultural, automotive, and construction applications with low viscosity petroleum fuels (gasoline, diesel fuel, and kerosene). Delivering flow rates up to 15 GPM (57 L/min) in two available pump models the M-240S Manual, and the M-240S Pump only. The M-240 Series is durable, manufactured from high-quality die-cast aluminum, easy to use, and engineered to last featuring a self-priming rotary gear design.
Features & Benefits
- Rotary gear design reduces wear and high quality 24-VDC motor provide more operating hours for maximum value.
- Convenient spin collar for easy installation and versatile pump mounting.
- Circuit breaker motor protection extends motor life.
- Light-weight aluminum body provides corrosion resistance and reduces tank stress.
- Lockable nozzle holder protects your investment and deters fuel theft.
- Designed for permanent mounting on vented storage tanks.
- UL Listed Motor and CSA Certified
- Rotary gear design reduces wear and high quality 24-VDC motor provide more operating hours for maximum value.
- Convenient spin collar for easy installation and versatile pump mounting.
- Circuit breaker motor protection extends motor life.
- Light-weight aluminum body provides corrosion resistance and reduces tank stress.
- Lockable nozzle holder protects your investment and deters fuel theft.
- Designed for permanent mounting on vented storage tanks.
- For ground-based refueling only. Do not use or mount in or on the aircraft. For use with aviation gasoline (AVGAS 100LL) and kerosene grade (JET A). User should consult NFPA 407 Standard for Aircraft Fuel Servicing for safety requirements during ground fuel ser¬vicing of aircraft using liquid petroleum fuels. This product has no actual or implied compliance with this standard.
Specifications
- Input:
- 24V (DC)
- Fuse:
- 15 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Dispensing Hose:
- 12 ft.(3.7m) x 3/4 in. MNPT
- Nozzle:
- 3/4 in. FNPT Inlet, Manual Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401124521
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
- Input:
- 24V (DC)
- Fuse:
- 15 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 1900
- Motor HP:
- 1/5
- Flow Rate:
- 15 GPM (57 L/min)
- Duty Cycle:
- 30 min on/30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Not included
- Power Cord:
- Power cord Not Included
- Dispensing Hose:
- Not included
- Nozzle:
- Not included
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401002522
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- CE. Complies with the requirements of the EMC Directive 89/336/EEC
Also Available At
Manuals / Documents
Applications
What's in the Box
Includes the M-240S 15 GPM pump with spin collar, manual unleaded nozzle, lockable nozzle holder, dispensing hose, factory-installed power cord, telescoping suction pipe, tank adapter, fuse assembly, owners manual.
Includes the M-240S-PO 24V 15 GPM pump with spin collar, lockable nozzle holder, power cord, tank adapter, fuse assembly, owners manual.
