20 Gallon per 100 Stroke Lever Action Fluid Transfer Hand Pump

GPI® DP-20 Series

SKU 138000-02 | MODEL DP-20 UL
Original price $319.99 - Original price $319.99
Original price
$319.99
$319.99 - $319.99
Current price $319.99

Recommended for use with these fuels:

Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Hydraulic Fluid | Up to 30W Oil

The GPI DP-20 fluid transfer hand pump is a lever-action diaphragm pump that delivers up to 20 gallons per 100 strokes and provides exceptional performance year after year. Its maintenance-free design reduces the number of internal moving parts which greatly reduces wear and binding seen with conventional hand pumps. The DP-20 hand pump is compatible with a wide variety of petroleum products.

Features & Benefits

  • Lever action diaphragm pump with lockable handle, deters theft.
  • Can be used to pump dirty or contaminated fluids
  • Lightweight, die-cast aluminum housing for easy installation.
  • Lock nut for securing pump orientation on tank
  • Designed to give you maximum reliability and efficiency.
  • Stainless steel piston shaft and Buna-N diaphragm and seals for long pump life.
  • Built-in air valve to prevent leakage at nozzle.
  • 2-yr Warranty
  • U.L. Listed
Product Model Options: UL Listed
Specifications
Flow Range:
N/A
Input:
N/A
Fuse:
N/A
Type:
Diaphragm
Motor RPMs:
N/A
Motor HP:
4/10
Flow Rate:
Up to 20 gallons per 100 stroke cycles
Duty Cycle:
N/A
Working Pressure:
N/A
Max Working Temperature:
-20° F to 125° F (-29° C to 52° C)
Wetted Materials:
Aluminum
Inlet:
1 in. FNPT
Outlet:
3/4 in. FNPT
Mounting Type:
Direct Mount, 2in. MNPT
Suction Pipe:
Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
Power Cord:
N/A
Dispensing Hose:
8 ft. (2.44 m) x 3/4 in.
Nozzle:
Spout, Thermoplastic
Housing:
Corrosion-Resistant Aluminum
Warranty:
2-yr pump warranty
UPC:
031401000603
Approvals:
UL Listed Hand Operated Pump for Flammable and Combustible Liquids Per UL Subject 124
Manuals / Documents
Applications


  • Garage

  • Barn

  • On top of a Barrel

  • In the Back of the Truck

What's in the Box
Includes the DP-20-UL 20 GPM per 100 stroke cycles hand pump, telescoping suction pipe, dispensing hose with spout, lockable lever, owner's manual.
