GPI 8 GPM 12V Fuel Transfer Pump
GPI® EZ8 Series
SKU 137100-05
| MODEL EZ-8 with Spin Collar
| MODEL EZ-8
Original price
$329.99
-
Original price
$349.99
Original price
$349.99
$329.99
-
$349.99
Current price
$349.99
Fluid Statement
Gasoline up to E15 | Diesel up to B20 | Kerosene Gasoline up to E15 | Diesel up to B20 | KeroseneThe GPI 12V DC EZ-8 Fuel Transfer Pump Series is the pump of choice for refueling recreational vehicles featuring a rotary gear design made from durable, lightweight corrosion-resistant diecast aluminum. The 12V DC motor delivers gas station equivalent flow rates of up to 8 GPM for gasoline, diesel fuel, ethanol blends, and kerosene. It is the perfect pump for on-the-go fueling for agriculture and automotive applications. Mount this dependable pump to fuel drums or tanks up to 100 gallons, and you are ready to go off-roading, cruise the lake, or achieve "yard of the week" mowing status. Spin collar model and Methanol pump only model available. If you are looking for an EZ-8 RV pump, please contact ECI Fuel Systems
Features & Benefits
- Gas station equivalent flowrate (up to 8 GPM). Self-priming low maintenance design
- Extremely lightweight design, less stress small tanks and barrels
- Installs easily with spin collar mount.
- Powder-coated aluminum body is corrosion resistant.
- For use with gasoline, diesel fuel, ethanol blends, and kerosene
- Thermal overload protection extends pump life.
- Motor U.L. listed to U.S. and Canadian standards
- 2-year warranty
- Gas station equivalent flowrate (up to 8 GPM). Self-priming low maintenance design
- Extremely lightweight design, less stress on small tanks and barrels
- Easy installation and direct tank mounting
- Powder-coated aluminum body provides corrosion resistance.
- For use with gasoline, diesel fuel, ethanol blends, and kerosene
- Thermal overload protection extends pump life
- Motor U.L. listed to U.S. and Canadian standards
- 2-yr pump warranty
Specifications
- Flow Range:
- N/A
- Input:
- 12V (DC)
- Fuse:
- 20 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 2100
- Motor HP:
- 1/10
- Flow Rate:
- 8 GPM (30 L/min)
- Duty Cycle:
- 15 min on / 30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Spin Collar, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 15 ft. (4.6m), 14/2 AWG, Factory Installed
- Dispensing Hose:
- 10 ft. (3.05m) x 5/8 in.
- Nozzle:
- 3/4 in. FNPT Inlet, Manual Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401137101
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Flow Range:
- N/A
- Input:
- 12V (DC)
- Fuse:
- 20 amps
- Type:
- Rotary Gear
- Motor RPMs:
- 2100
- Motor HP:
- 1/10
- Flow Rate:
- 8 GPM (30 L/min)
- Duty Cycle:
- 15 min on / 30 min off
- Working Pressure:
- 15 PSI (1.03 bar)
- Max Working Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Inlet:
- 1 in. FNPT
- Outlet:
- 3/4 in. FNPT
- Mounting Type:
- Direct Mount, 2in. MNPT
- Suction Pipe:
- Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Power Cord:
- 15 ft. (4.6m), 14/2 AWG, Factory Installed
- Dispensing Hose:
- 10 ft. (3.05m) x 5/8 in.
- Nozzle:
- 3/4 in. FNPT Inlet, Manual Shut-off, Unleaded
- Housing:
- Powder Coated, Corrosion-Resistant Diecast Aluminum
- Warranty:
- 2-yr pump warranty
- UPC:
- 031401137101
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
Also Available At
Manuals / Documents
Applications
What's in the Box
EZ-8 8 GPM pump with spin collar, manual unleaded nozzle, dispensing hose w/static wire, factory-installed power cord, telescoping suction pipe, street elbow, tank adapter, fuse assembly, owners manual.
EZ-8 8 GPM pump, manual unleaded nozzle, dispensing hose w/static wire, factory-installed power cord, telescoping suction pipe, street elbow, tank adapter, fuse assembly, owners manual.
