2-40 GPM Modular Mechanical Fuel Meter
GPRO® QM40 Series
Recommended for use with these fuels:
Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Avgas (100LL) | Jet A Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Avgas (100LL) | Jet AThe GPRO QM40 Mechanical Fuel Meter provides precision fuel measurements for more accurate readings for fleet operations, heavy equipment, and agricultural applications. It features a magnetic drive mechanism that is nearly frictionless; less friction results in more flow, capable of handling flow rates up to 40 GPM. The QM40 is equipped with both NPT and Flange connections which allows it to be installed on all threaded pump outlets or modular GPI products.
For ground-based refueling only. Do not use or mount in or on the aircraft. For use with aviation gasoline (Avgas 100LL), Jet A, and Jet A-1 . User should consult NFPA 407 Standard for Aircraft Fuel Servicing for safety requirements during ground fuel servicing of aircraft using liquid petroleum fuels. This product has no actual or implied compliance with this standard. Owners and operators are responsible for compliance to all applicable regulations.
Features & Benefits
- Includes Quick-Fit modular connections, easily attaches to the new GPI modular fuel transfer pumps
- Extreme Accuracy, within +/- 1/2% across a flow range from 2 to 40 GPM.
- 1" NPT threaded inlet and outlet adapters are included for installation with pipe fittings
- Magnetic Drive eliminates drive shaft leaks.
- Gallon register rotates to read easily in any application; four-digit display, twist knob reset
- Optional pulser accessory is compatible with most fuel management systems
- Oval Gear technology at an affordable price
- Includes Quick-Fit modular connections, easily attaches to the new GPI modular fuel transfer pumps
- Extreme Accuracy, within +/- 1/2% across a flow range from 2 to 40 GPM.
- 1" NPT threaded inlet and outlet adapters are included for installation with pipe fittings
- Oval Gear technology at an affordable price
- Litre register rotates to read easily in any application; four-digit display, twist knob reset
- Optional pulser accessory is compatible with most fuel management systems
- Magnetic Drive eliminates drive shaft leaks.
Specifications
- Flow Range:
- 2 - 40 GPM (8-150 L/min)
- Accuracy (% of Reading):
- +/- 1/2% across flow range from 2-40 GPM (8-150 L/min)
- Technology:
- Oval Gear
- Pressure Rating:
- 50 PSI (3.45 bar)
- Operating Temperature:
- -40° F to 125° (-40° C to 52° C)
- Connection Type/Size:
- Modular with NPT (Female) Adapter, 1-inch
- Meter Housing Material:
- Corrosion-Resistant Aluminum
- Wetted Materials:
- Acetal | Aluminum | NBR | Neodymium | PPS | Stainless Steel
- Warranty:
- 5-year meter warranty
- UPC:
- 031401008791
- Approvals:
- U.L Listed to U.S. and Canadian Standards
- Flow Range:
- 2 - 40 GPM (8-150 L/min)
- Accuracy (% of Reading):
- +/- 1/2% across flow range from 2-40 GPM (8-150 L/min)
- Technology:
- Oval Gear
- Pressure Rating:
- 50 PSI (3.45 bar)
- Operating Temperature:
- -40° F to 125° (-40° C to 52° C)
- Connection Type/Size:
- Modular with NPT (Female) Adapter, 1-inch
- Meter Housing Material:
- Corrosion-Resistant Aluminum
- Wetted Materials:
- Acetal | Aluminum | NBR | Neodymium | PPS | Stainless Steel
- Warranty:
- 5-year meter warranty
- UPC:
- 031401008807
- Approvals:
- U.L Listed to U.S. and Canadian Standards
Manuals / Documents
What's in the Box
