GPRO 35 GPM 115V Fuel Transfer Pump
GPRO® PRO35-115 Series
SKU 504000-03
| MODEL PRO35-115AD
| MODEL PRO35-115PO
Original price
$1,599.99
-
Original price
$1,799.99
Original price
$1,799.99
$1,599.99
-
$1,799.99
Current price
$1,799.99
Recommended for use with these fuels:
Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene Gasoline up to E15 | Diesel Fuel up to B20 | Kerosene | Avgas (100LL) | Jet A
The GPRO PRO35-115 professional-grade fuel transfer pump is the pump of choice for your large stationary fuel tanks. This powerful pump will fill even the biggest fuel tanks quickly and easily so you can go back to clearing debris, planting crops, or stacking lumber. Available in a variety of configurations to meet your application's needs. The 115V AC motor delivers flow rates up to 35 GPM (132 L/min) for applications with low viscosity petroleum fuels such as gasoline, diesel fuel, and kerosene. Extreme temperature series (XTS) model, and Pump and meter combinations available for the complete package.
Features & Benefits
- Compatible with Hose Reel
- High Pressure Pump
- High Flow Rate
- Extended duty cycle exceeds industry standards
- Thermally protected motor
- Field replaceable switch and vanes
- Vacuum breaker ready
- Center base inlet with check valve
- Compatible with Hose Reel
- High Pressure Pump
- High Flow Rate
- Extended duty cycle exceeds industry standards
- Thermally protected motor
- Field replaceable switch and vanes
- Vacuum breaker ready
- For ground-based refueling only. Do not use or mount in or on the aircraft. For use with aviation gasoline (Avgas 100LL), Jet A, and Jet A-1. User should consult NFPA 407 Standard for Aircraft Fuel Servicing for safety requirements during ground fuel servicing of aircraft using liquid petroleum fuels. This product has no actual or implied compliance with this standard. Owners and operators are responsible for compliance to all applicable regulations.
Specifications
- Max. Flow Rate:
- 35 GPM (132 L/min)
- Voltage Input:
- 115V (AC) 60Hz, 230V (AC) 60Hz Dual Voltage Configurable
- Technology:
- Sliding Vane
- Amps Rated:
- 9.8 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- Power cord Not Included
- Max. Discharge Pressure:
- 25 PSI (1.72 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 15 ft. (4.5 m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 18 ft. (5.5 m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Powder Coated Cast Iron
- Wetted Materials:
- Acetal | Aluminum | Carbon | Cast Iron | FKM | NBR | PBT/Polyester | Steel
- Mounting Type/Thread:
- Direct Mount, 2in. MNPT
- Suction Pipe:
- Not included
- Inlet:
- 1.25-inch FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- 18ft. (5.5m) x 1 in. MNPT UL Listed Hose Assembly
- Nozzle:
- 1 in. FNPT Inlet, Automatic Shut-off, Diesel
- Nozzle Holder Type:
- Lockable
- Warranty:
- 5-year pump warranty
- UPC:
- 031401003581
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
- Approvals (cont'd):
- cULus Power-Operated Pumps for Petroleum Products
- Max. Flow Rate:
- 35 GPM (132 L/min)
- Voltage Input:
- 115V (AC) 60Hz, 230V (AC) 60Hz Dual Voltage Configurable
- Technology:
- Sliding Vane
- Amps Rated:
- 9.8 amps
- Duty Cycle:
- 30 min on/30 min off
- Power Cord:
- Power cord Not Included
- Max. Discharge Pressure:
- 25 PSI (1.72 bar)
- Operating Temperature:
- -20° F to 125° F (-29° C to 52° C)
- Suction Lift:
- Up to 15 ft. (4.5 m) at Sea Level 70° F (21.1° C)
- Discharge Lift:
- Up to 18 ft. (5.5 m) at Sea Level 70° F (21.1° C)
- Pump Housing Material:
- Powder Coated Cast Iron
- Wetted Materials:
- Acetal | Aluminum | Carbon | Cast Iron | FKM | NBR | PBT/Polyester | Steel
- Mounting Type/Thread:
- Direct Mount, 2in. MNPT
- Suction Pipe:
- Not included
- Inlet:
- 1.25-inch FNPT
- Outlet:
- 1 in. FNPT
- Dispensing Hose:
- Not included
- Nozzle:
- Not included
- Nozzle Holder Type:
- Lockable
- Warranty:
- 5-year pump warranty
- UPC:
- 031401003567
- Approvals:
- cULus Motor Listed for Hazardous Locations Class I, Division 1, Group D USA and Canada
- Approvals (cont'd):
- cULus Power-Operated Pumps for Petroleum Products
Also Available At
Manuals / Documents
Applications
What's in the Box
PRO35-115AD 115/230V 35 GPM pump, Automatic shut-off diesel nozzle, Dispensing hose, Tank adapter, Lockable nozzle holder, Owner's manual
PRO35-115PO 115/230V 35 GPM Pump, Tank adapter, Lockable nozzle holder, Owner's manual
