Turbine, High-Temp Brew Meter, Battery-Powered Display, Tri-Clamp Fittings
FLOMEC® G2 Series
SKU G2S05TH9GMX
| MODEL G2S-05-T-H
| MODEL G2S-07-T-H
| MODEL G2S-10-T-H
| MODEL G2S-15-T-H
| MODEL G2S-20-T-H
Original price
$1,111.00
-
Original price
$1,846.00
Original price
$1,111.00
$1,111.00
-
$1,846.00
Current price
$1,111.00
Recommended for use with these liquids:
Strike water | Hot water flow | Brewing liquids Strike water | Hot water flow | Brewing liquids Strike water | Hot water flow | Brewing liquids Strike water | Hot water flow | Brewing liquids Strike water | Hot water flow | Brewing liquidsMake your perfect recipe every time! The FLOMEC G2 Brew Meter features a high-temperature riser and Tri-Clamp fittings. It’s highly dependable and affordable, making it a great choice for small-batch brewers.
Features & Benefits
- Features highly visible Q9, battery-powered, LCD display; 2-year battery life
- High accuracy meter –view SPECIFICATIONS of each SKU once meter options are selected
- Modular design allows for use with output modules, sensors, and remote display kits; plug and play
- Internal parts are simple to replace for easy maintenance
- 11 pre-programmed engineering units plus 1 custom option: gallon, litre, imperial gallon, quart, ounce, acre-foot, millilitre, cubic foot, cubic centimetre, cubic metre, barrel
- Tri-clamp, high temperature, sanitary fittings: ¾-inch fitting for ½-inch pipe, 1-inch fitting for ¾-inch pipe, 1-½-inch fitting for 1-inch pipe, 2-inch fitting for 1-½-inch pipe, 2-½-inch fitting for 2-inch pipe. For a food-safe metering option, view G Series.
- Features highly visible Q9, battery-powered, LCD display; 2-year battery life
- High accuracy meter –view SPECIFICATIONS of each SKU once meter options are selected
- Modular design allows for use with output modules, sensors, and remote display kits; plug and play
- Internal parts are simple to replace for easy maintenance
- 11 pre-programmed engineering units plus 1 custom option: gallon, litre, imperial gallon, quart, ounce, acre-foot, millilitre, cubic foot, cubic centimetre, cubic metre, barrel
- Tri-clamp, high temperature, sanitary fittings: ¾-inch fitting for ½-inch pipe, 1-inch fitting for ¾-inch pipe, 1-½-inch fitting for 1-inch pipe, 2-inch fitting for 1-½-inch pipe, 2-½-inch fitting for 2-inch pipe. For a food-safe metering option, view G Series.
- Features highly visible Q9, battery-powered, LCD display; 2-year battery life
- High accuracy meter –view SPECIFICATIONS of each SKU once meter options are selected
- Modular design allows for use with output modules, sensors, and remote display kits; plug and play
- Internal parts are simple to replace for easy maintenance
- 11 pre-programmed engineering units plus 1 custom option: gallon, litre, imperial gallon, quart, ounce, acre-foot, millilitre, cubic foot, cubic centimetre, cubic metre, barrel
- Tri-clamp, high temperature, sanitary fittings: ¾-inch fitting for ½-inch pipe, 1-inch fitting for ¾-inch pipe, 1-½-inch fitting for 1-inch pipe, 2-inch fitting for 1-½-inch pipe, 2-½-inch fitting for 2-inch pipe. For a food-safe metering option, view G Series.
- Features highly visible Q9, battery-powered, LCD display; 2-year battery life
- High accuracy meter –view SPECIFICATIONS of each SKU once meter options are selected
- Modular design allows for use with output modules, sensors, and remote display kits; plug and play
- Internal parts are simple to replace for easy maintenance
- 11 pre-programmed engineering units plus 1 custom option: gallon, litre, imperial gallon, quart, ounce, acre-foot, millilitre, cubic foot, cubic centimetre, cubic metre, barrel
- Tri-clamp, high temperature, sanitary fittings: ¾-inch fitting for ½-inch pipe, 1-inch fitting for ¾-inch pipe, 1-½-inch fitting for 1-inch pipe, 2-inch fitting for 1-½-inch pipe, 2-½-inch fitting for 2-inch pipe. For a food-safe metering option, view G Series.
- Features highly visible Q9, battery-powered, LCD display; 2-year battery life
- High accuracy meter –view SPECIFICATIONS of each SKU once meter options are selected
- Modular design allows for use with output modules, sensors, and remote display kits; plug and play
- Internal parts are simple to replace for easy maintenance
- 11 pre-programmed engineering units plus 1 custom option: gallon, litre, imperial gallon, quart, ounce, acre-foot, millilitre, cubic foot, cubic centimetre, cubic metre, barrel
- Tri-clamp, high temperature, sanitary fittings: ¾-inch fitting for ½-inch pipe, 1-inch fitting for ¾-inch pipe, 1-½-inch fitting for 1-inch pipe, 2-inch fitting for 1-½-inch pipe, 2-½-inch fitting for 2-inch pipe. For a food-safe metering option, view G Series.
Specifications
- Flow Range:
- 1 - 10 GPM (3.8-38 L/min)
- Accuracy (% of Reading):
- +/- 1.5%
- Technology:
- Turbine
- Pressure Rating:
- Limited by fitting, clamp size, & temperature
- Operating Temperature:
- 0° F to 185° F (-18° C to 85° C)
- Connection Type/Size:
- Tri-Clamp, 3/4-inch
- Pipe Size:
- 1/2-inch
- Meter Housing Material:
- Stainless Steel
- Wetted Materials:
- 316 Stainless Steel | Ceramic | PVDF | Tungsten Carbide
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401009590
- Approvals:
- CE, NEMA 4, IP65
- Flow Range:
- 2 - 20 GPM (7.6-76 L/min)
- Accuracy (% of Reading):
- +/- 1%
- Technology:
- Turbine
- Pressure Rating:
- Limited by fitting, clamp size, & temperature
- Operating Temperature:
- 0° F to 185° F (-18° C to 85° C)
- Connection Type/Size:
- Tri-Clamp, 1-inch
- Pipe Size:
- 3/4-inch
- Suction Lift:
- N/A
- Meter Housing Material:
- Stainless Steel
- Wetted Materials:
- 316 Stainless Steel | Ceramic | PVDF | Tungsten Carbide
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401009606
- Approvals:
- CE, NEMA 4, IP65
- Flow Range:
- 5 - 50 GPM (19-190 L/min)
- Accuracy (% of Reading):
- +/- 1%
- Technology:
- Turbine
- Pressure Rating:
- Limited by fitting, clamp size, & temperature
- Operating Temperature:
- 0° F to 185° F (-18° C to 85° C)
- Connection Type/Size:
- Tri-Clamp, 1-1/2-inch
- Pipe Size:
- 1-inch
- Suction Lift:
- N/A
- Meter Housing Material:
- Stainless Steel
- Wetted Materials:
- 316 Stainless Steel | Ceramic | PVDF | Tungsten Carbide
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401009613
- Approvals:
- CE, NEMA 4, IP65
- Flow Range:
- 10 - 100 GPM (38-380 L/min)
- Accuracy (% of Reading):
- +/- 0.75%
- Technology:
- Turbine
- Pressure Rating:
- Limited by fitting, clamp size, & temperature
- Operating Temperature:
- 0° F to 185° F (-18° C to 85° C)
- Connection Type/Size:
- Tri-Clamp, 2-inch
- Pipe Size:
- 1-1/2-inch
- Suction Lift:
- N/A
- Meter Housing Material:
- Stainless Steel
- Wetted Materials:
- 316 Stainless Steel | Ceramic | PVDF | Tungsten Carbide
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401009620
- Approvals:
- CE, NEMA 4, IP65
- Flow Range:
- 20 - 200 GPM (76-760 L/min)
- Accuracy (% of Reading):
- +/- 0.75%
- Technology:
- Turbine
- Pressure Rating:
- Limited by fitting, clamp size, & temperature
- Operating Temperature:
- 0° F to 185° F (-18° C to 85° C)
- Connection Type/Size:
- Tri-Clamp, 2-1/2-inch
- Pipe Size:
- 2-inch
- Suction Lift:
- N/A
- Meter Housing Material:
- Stainless Steel
- Wetted Materials:
- 316 Stainless Steel | Ceramic | PVDF | Tungsten Carbide
- Warranty:
- 2-yr meter warranty
- UPC:
- 031401009637
- Approvals:
- CE, NEMA 4, IP65
Manuals / Documents
What's in the Box
Turbine flowmeter, Local Digital Display, HIgh-Temperature Riser, (2) alkaline AAA batteries, Owners Manuals
Turbine flowmeter, Local Digital Display, HIgh-Temperature Riser, (2) alkaline AAA batteries, Owners Manuals
Turbine flowmeter, Local Digital Display, HIgh-Temperature Riser, (2) alkaline AAA batteries, Owners Manuals
Turbine flowmeter, Local Digital Display, HIgh-Temperature Riser, (2) alkaline AAA batteries, Owners Manuals
Turbine flowmeter, Local Digital Display, HIgh-Temperature Riser, (2) alkaline AAA batteries, Owners Manuals
